Phillips 66 Armor 5w-30

Phillips 66® Shield Armor Full Synthetic Motor Oil  высококачественное, полностью синтетическое моторное масло для бензиновых двигателей. Обеспечивающее высокую степень защиты атмосферных и турбированных двигателей с инжектором или непосредственным впрыском топлива, а также автомобилей использующих альтернативные виды топлива. Рекомендуется к использованию в легковых автомобилях и грузовиках малой грузоподъемности, работающих в экстремальных температурах или тяжелых условиях эксплуатации, таких как буксировка грузов и т.д.

Shield Armor Full Synthetic Motor Oil создан на основе высокакачественных базовых маслах.  Полностью синтетическая формула обеспечивает высокую защиту от отложений при высоких температурах и обеспечивает стабильную вязкость, меньшую испоряемость, а также низкую температуру замерзания, обеспечивая защиту при холодных запусках.

Shield Armor Full Synthetic Motor Oil превосходит требования к новым автомобилям ILSAC GF-5 (кроме 0W-16). It is uniquely formulated to help combat low speed pre-ignition (LSPI) in turbocharged gasoline direct injection engines. It meets or exceeds “Resource Conserving” requirements for fuel economy improvement, emission system and turbocharger protection, and protection of engines operating on ethanol-containing fuels up to E85. It is backward serviceable for use where API SN or earlier “S” category engine oils are recommended.

Applications

• Turbocharged gasoline direct-injection, conventional gasoline-fueled and flex-fuel passenger cars, light trucks and sport utility vehicles, including gasoline-electric hybrids, especially when operating under severe conditions

• Four-stroke cycle gasoline engines in other mobile or stationary equipment Shield Armor Full Synthetic Motor Oil is licensed for:

• ILSAC GF-5 (except 0W-16)

• API Service SN Plus with Resource Conserving Shield Armor Full Synthetic Motor Oil meets or exceeds the requirements of:

• Chrysler MS-6395 (except 0W-16)

• Ford WSS-M2C945-B1 (SAE 5W-20)

• Ford WSS-M2C946-B1 (SAE 5W-30)

• Ford WSS-M2C947-B1 (SAE 0W-20)

• GM6094M (obsolete specification) (does not include 0W-16)

Features/Benefits

• Helps protect against low speed pre-ignition (LSPI) in turbocharged gasoline direct-injection engines (TGDI)

• Exceeds ILSAC GF-5 requirements for new cars under warranty (except 0W-16)

• Enhanced performance benefits at extreme temperatures compared with conventional engine oils

• Outstanding resistance to viscosity and thermal breakdown at high temperatures

• Protects against sludge and varnish formation

• Protects against rust and bearing corrosion

• Low volatility for reduced oil consumption

• Excellent low temperature pumpability for protection during cold starts

• Highly resistant to foaming

• Formulated to protect turbochargers and emission control system catalysts

• Formulated for use in vehicles operating on ethanol-containing fuels up to E85

Shield® Armor Typical Properties

SAE Grade 0W-16 \ 0W-20 \ 5W-20 \ 5W-30 \ 10W-30

Specific Gravity @ 60°F 0.846 \ 0.847 \ 0.848 \ 0.851 \ 0.852

Density, lbs/gal @ 60°F 7.05 \ 7.05 \ 7.06 \ 7.09 \ 7.10

Color, ASTM D1500 3.0 \ 3.0 \ 3.0 \ 3.0 \ 3.0

Flash Point (COC), °C (°F) 229 (444) \ 229 (444) \ 229 (444) \ 235 (455) \ 232 (450)

Pour Point, °C (°F) -43 (-45) \ -43 (-45) \ -41 (-42) \ -40 (-40) \ -39 (-38)

Viscosity, Kinematic

cSt @ 40°C 37.3 \ 46.0 \ 45.4 \ 61.2 \ 63.2

cSt @ 100°C 7.3 \ 8.8 \ 8.4 \ 10.9 \ 10.4

Viscosity Index 163 \ 174 \ 164 \ 171 \ 153

Cold Cranking Viscosity,

cP 5,000 \ 5,000 \ 3,650 \ 4,900 \ 3,750

@ (°C) (-35) \ (-35) \ (-30) \ (-30) \ (-25)

High Temp/High Shear Viscosity,

cP @ 150°C 2.3 \ 2.6 \ 2.6 \ 3.0 \ 3.1

Sulfated Ash, ASTM D874,

wt % 0.96 \  0.96 \ 0.96 \ 1.02 \ 0.96

Total Base Number (TBN),

ASTM D2896 8.0 \ 8.0 \ 8.0 \ 8.6 \ 8.0

Phosphorus, wt % 0.77 \ 0.077 \ 0.077 \ 0.077 \ 0.077

Zinc, wt % 0.085 \ 0.085 \ 0.085 \ 0.085 \ 0.085
